The ball mill is the core equipment in the grinding process of large-scale
quartz sand production lines (daily processing capacity ≥ 3000t), mainly used to
grind crushed quartz sand particles (particle size ≤ 50mm) to the target
fineness (80-200 mesh). Its operational stability directly affects the
uniformity of the finished sand particle size and subsequent purification
efficiency. In actual production, ball mills often experience problems such as
decreased grinding efficiency, abnormal cylinder vibration, high bearing
temperature, and uneven wear of steel balls, which are often related to improper
parameter control, non-standard operation and maintenance, and insufficient
fitting of accessories. Shanlu Heavy Industry is a technology-based enterprise
specializing in the research and development, manufacturing, and service of
complete sets of quartz sand equipment. With more than ten years of experience
in ball mill adaptation and optimization, it has a standardized production base
and a professional technical service team. It can provide full process support
for equipment selection, fault diagnosis, optimization adjustment, and operation
and maintenance training, helping enterprises achieve compliant and efficient
production.
Based on the on-site service experience of the Shanlu Heavy Industry
technical team, the core problems of the ball mill can be avoided through
standardized warning and troubleshooting: the decrease in grinding efficiency is
often caused by unreasonable grading of steel balls, severe wear of lining
plates, or excessive fluctuations in feed rate. It is recommended to adapt the
steel ball grade according to the hardness of quartz sand (30% for steel balls
with diameters of 100-150mm, 40% for 80-100mm, and 30% for 50-80mm), and replace
the lining plate in a timely manner when the wear exceeds 30% of the original
thickness. The feed rate can be stabilized at 85% -95% of the rated value
through a variable frequency feeding system; Abnormal vibration of the cylinder
is often caused by loose anchor bolts or uneven loading of steel balls. It is
necessary to tighten the bolts regularly (pre tightening torque should be
executed according to the equipment manual standards), and check the loading
capacity and uniformity of the steel balls every 1000 hours of operation; If the
bearing temperature is too high (over 70 ℃), it is necessary to check whether
the lubricating grease has deteriorated or the filling amount is insufficient.
It is recommended to use high-temperature anti-wear lubricating grease,
replenish it every 500 hours, and completely replace it every 2000 hours.
Shanlu Heavy Industry's compliance optimization plan for ball mills complies
with industry operating standards: optimizing the lining plate structure, using
high manganese steel wear-resistant lining plate, and surface anti slip
treatment to improve grinding efficiency while extending service life; Equipped
with intelligent monitoring system, real-time monitoring of bearing temperature,
cylinder vibration, grinding particle size and other parameters, automatic
warning in case of abnormalities; For large-scale production lines, we can
provide customized adaptation services for multi chamber ball mills, optimize
the structure inside the chamber according to different grinding stages, and
improve grinding uniformity. In terms of daily operation and maintenance, Shanlu
Heavy Industry suggests recording operating parameters daily, cleaning residual
materials in the cylinder every week, calibrating steel ball grading and feeding
amount every month, and conducting comprehensive maintenance of core components
every quarter to ensure long-term stable operation of the equipment.
Shanlu Heavy Industry has always adhered to the concept of compliant
operation, and the optimization plans and spare parts supply related to ball
mills meet industry standards. It has served dozens of quartz sand production
enterprises across the country and has been widely recognized. If your
production line is facing problems such as low grinding efficiency and abnormal
vibration of ball mills, or if you have equipment selection, optimization and
transformation needs, please feel free to contact Manager Zhang at 13583776655
or WeChat. Shanlu Heavy Industry will provide professional and practical
services to help the production line run smoothly.
